FAST/SINILOOM rapier weaving machine is an advanced model based on the introduction of the Italian SMIT FAST type rapier weaving machine and improved based on the actual situation of domestic material supply and process manufacturing. FAST/SINILOOM rapier weaving machine adopt conjugate cam beating, shed spatial linkage insertion without guide, and micro-computer controlled automatic weft finding, the variety adaptability is wide, suitable for cotton or synthetic yarn, combed wool yarn and filaments, can weaving wool and worsted fabrics, light and medium cotton fabrics, twill cotton fabrics and corduroy fabrics, as well as rayon, synthetic fibers, silk and other fabrics. The weft insertion mechanism of this machine has high precision, good rigidity, low acceleration of the movement of the gripper, no excessive yarn deformation during weft insertion, and convenient for weft clipping, weft cutting and weft yarn transferring. When changing the width, it is not required to adjust the time when the gripper is handed over at the center; the gripper band runs smoothly, does not require the gripper band guide hooks avoids the interference of the guide hook on the warp yarn, and can adapt to the weaving of the high-density fabric or the delicate yarn requirements; electronic let-off and electronic take-up systems have a wide range of adaptability, while the control system provides a variety of ways of weft finding and weave compensation, can avoid start mark in most cases. At present, FAST/ SINILOOM rapier weaving machine also have derivative products such as able looms and wide width jacquard looms.
Master/Xinlong series rapier loom is a A loom in which the rapier transfers the weft in the center of the loom.
The loom has a wide range of yarn counts:
- Cotton and synthetic fibers, from 500tex (1.2Ne) to 5tex (120Ne) - Coarse and fine wool yarns, from 680tex (1.5Nm) to 10tex (100Nm) - Filament, from 10dtex (9den) to 1650dte (1485 den)
The product enables the cost-effective production of an extremely wide variety of fabrics:
- Wool and worsted wool fabrics -Light and medium weight cotton fabrics - Fine twill cotton and corduroy -Rayon, synthetic silk, silk fabrics -Light and medium weight cotton upholstery or blend upholstery -Light and medium heavy duty industrial fabrics - Fabric weight range: 40 grams per square meter to 450 grams per square meter

♦ The width of the product ranges from 190 to 360 cm; there is no rapier guide rail in the shed, which reduces the interference to the warp yarn; the reed moves smoothly, which reduces the vibration of the loom and reduces the noise level, so that the Master/Xinlong series products have the Remarkable stability. ♦Adopt a freely programmable eight-color electronic weft selection device with high reliability of weft selection. The cutting time of the weft scissors can be adjusted precisely and simply. ♦ The reciprocating rotation of the transmission wheel is completed by the four-phase hinge mechanism, which is composed of several components with extremely high strength and precise dimensions, which is easy to adjust and maximizes the flexibility of operation.
♦The characteristic of the rapier movement is that its acceleration is low, and the running speed curve does not cause excessive weft deformation during weft insertion, which is convenient for weft clamping, weft cutting, weft transfer and weft release. ♦The optimal shed shape is designed through detailed stress research on the elasticity of various warp and weft yarns. The reed's beating-up angle, shed geometry, and wide adjustment range of the back beam make it more prominent when processing high-density fabrics and fabrics with high coverage factors. ♦ Microcomputer control to automatically search for weft breakage, and a series of phase correction programs to find weft breakage can be selected according to the type of fabric to prevent the stop gear from being generated. ♦The electronic control system of the loom has reliable performance and strong work adaptability.
